HOMAG - Optimat BAZ 211DE-CNC-HOM-2006-00001

Machine Benefits

Qualitative Machine Benefits

• Edge height: 16 – 65 mm
• The edge thickness capacity ranges from 0. 4 to 2 mm for plastic and extends up to 1 mm for wood.
• Glue application via nozzle directly on the panel
• Includes pre-cutting station and single-roll edge supply
• Roll diameter: 800 mm
• Saw-cutting unit
• Combined flush trimming and finishing unit
• Flex-5 multifunction unit (for sawing, milling, and drilling; interchangeable with main spindle)

Technical Machine Benefits

• The maximum workpiece length capacity is 4000 mm with single clamping, or 1375 mm in pendulum operation, extending to 1550 mm in pendulum operation when using a Ø25 mm milling tool.
• The maximum workpiece width capacity is 1730 mm when milling with a Ø25 mm tool, and 1600 mm for all other operations.
• Clamping table with led position indicators
• 18-position disc tool changer
• 360° edge banding unit
• Powerful main spindle with 15 kw motor
• Power: 15 kw (s6 mode) / 12 kw (s1 continuous)
• C-axis with interface for flex-5 unit
• 17 vertical spindles (11 in x, 7 in y)
• 4 horizontal spindles

Extra Information

Machine still under power
