FELDER - Tempora 45.03 LXDE-EDG-FEL-2019-00001
Haben Sie weitere Fragen? Kontaktieren Sie uns!
Philipp Gubisch
+49 162 402 75 81
p.gubisch@gindumac.com
- GINDUMAC
- Produkte
- Holzbearbeitung
- ➤ Used FELDER Tempora 45.03 LX For Sale | gindumac.com
This FELDER Tempora 45.03 LX edgebander was manufactured in 2018. It features a joining unit with a diamond cutter, a cross-cut saw unit with an adjustable angle, and a corner processing unit suitable for edge thicknesses up to 3 mm. The gluing unit is Teflon-coated and supports both EVA and PUR glues. Ideal for enhancing workshop capabilities, the FELDER Tempora 45.03 LX edgebander we have for sale. Contact us for further details regarding this edgebander.
Übersicht
- Hersteller: FELDER
- jahr: 2018
- MODELL: Tempora 45.03 LX
- anwendungstyp: Kantenanleimen
- Standort: Deutschland
- maschinentyp: Kantenanleimmaschine
Zusätzliche Informationen
Additional equipment
- Upper and lower radius scraper blades
- polishing units
- neumatic insertion lock for workpiece distance monitoring
- Lighting equipment: LED for Tempora 45.03L
- Optional: extraction unit with the complete pipework
Machine Benefits
Qualitative Machine Benefits
- Rcd to be connected upstream: type b, tripping current 300ma
- Segmented, rubberized support pads with quick-change system
Technical Machine Benefits
- Electrical: 3×400v, 50hz
- Speed: 9 m/min
- Drive motor: 0. 75 kw (s6)
- Minimum workpiece length: 140 mm
- Joining unit: 1. 5 kw, 12,000 rpm, max. Chip removal 2 mm, diamond cutter d-80 x 49 mm
- Cross-cut saw unit: high-frequency motor with 0. 35 kw, 12,000 rpm, adjustable cutting angle 0° to 10°
- Corner processing unit: for edge thicknesses of 0. 4-3 mm, min. Workpiece length 270 mm
- Flush and radius trimming unit: positioning-controlled, 0. 75 kw, 12,000 rpm (both top and bottom)
- Gluing unit: teflon-coated, for 1. 5 kg eva granulate, synchronized glue roller, suitable for pur glue
Extra Information
Machine still under power
*Es kann zu Abweichungen zwischen den angegebenen Daten und den tatsächlichen Werten kommen, diese müssen vom Vertriebsmitarbeiter bestätigt werden.
