TORNOS - DECO 10aDE-TUR-TOR-2003-00001

Additional information

• TB-DBCO Version 6 programming software: Single-user product, configuration available in 5 languages (French, German, English, Italian, Spanish)

• Programming language: ISO programming language

• Movable headstock: S1/Z1 axis, n = 16000 rpm, F13 collet chuck

• Spindle stop: Directional spindle stop S1 (programming increment 0.1 degrees)

• Cross-slides:

• 1 cross-slide with 4 tool holders (X1 and Y1 axes)

• 1 cross-slide with 3 tool holders (Z3 and X3 axes)

• 1 cross-slide with horizontal and vertical movement (Z4 and X4 axes)

• Pneumatic cylinders: 3 independent for quick positioning

• Counter-spindle: Independent (S4), n = 12000 rpm, F13 collet chuck

• Cross Slide Support Options:

• Pre-adjustable turning tool holder, long type, 8x8 mm cross-section

• Main spindle rotation direction: right

• S2 motorization (electric/mechanical) for driven units on the X2-Y2 linear tool carrier

• Driven end drilling/milling unit: Max. speed 12000 rpm

• Cross drilling/milling/tapping attachment for BSX 12 collet chuck

• Sensor: Tool breakage detection with TYPE MIDI-DETECTOR, oscillating probe type MINI-DETECTOR, electrical interface, pneumatic control equipment

• Interface: Adapting an LNS bar feeder

• Spinde Speed: n = 16000 rpm indicates the machine has a moderate spindle speed capacity.
