GROB - G550aDE-MIL-GRO-2020-00001

• Maximum speed of x-axis: 60 m/min / maximum speed of y'-axis: 42 m/min / maximum speed of z-axis: 60 m/min

• Maximum acceleration of x-axis: 5. 0 m/s² / maximum acceleration of y'-axis: 4. 5 m/s² / maximum acceleration of z-axis: 8. 0 m/s²

• Maximum feed force of x-axis: 8 kn / maximum feed force of y'-axis: 8 kn / maximum feed force of z-axis: 10 kn / position uncertainty of x/y'/z-axis: 0. 006 mm / repeat accuracy of positioning in x/y'/z-axis: <0. 0025 mm

• Total weight of the machining center: 20500 kg

• Maximum speed 16,000 min-1 / nominal speed 1,500 min-1 /

• Drive power of the spindle at 100% duty cycle 25. 0 kw / 40% duty cycle 32. 0 kw

• Maximum torque of the spindle at 100% duty cycle 159 nm / 40% duty cycle 206 nm

• Table: interference circle diameter: 900 mm

• 1180 spindle hours

The offer includes only the machine without tools or accessories.

Additional equipment

• Accessories: Additional pallet + coolant cooling unit
