- ➤ Used BÜRKLE FFAII 1300 - 2001 - For Sale
This thermo lamination system was manufactured in 2001. The BÜRKLE FFAII 1300 features a working width of 1300 mm and handles panel dimensions from 200 to 1300 mm in width and 400 to 3000 mm in length, with thickness ranging from 8 to 40 mm. It includes a thermal oil heater, smoothing calender, and a comprehensive transport and laminating system. Ideal for high-efficiency thermo lamination processes. For more information about this thermo lamination system, please reach out to us.
Übersicht
- Hersteller: BURKLE
- jahr: 2001
- MODELL: FFAII 1300
- anwendungstyp: Pressen / Laminieren
- Standort: Deutschland
- maschinentyp: Furnierpresse
Zusätzliche Informationen
Machine Benefits
Qualitative Machine Benefits
- System configuration ffaii 1300
- Panel pass-through: central
- Brushing machine dbm (chain brushes)
- Cooling unit for dow cooling
- Glue supply
- Cone transport track tke
- Laminating calender ekm, d = 500 mm + foil unwinding station + separation station + belt transport track with operator bridge for fve tension shafts
- Smoothing calender gkl, d = 500 mm at the inlet of the conveyor belt
Technical Machine Benefits
- Working width: 1300 mm
- Panel dimensions: width: 200 - 1300 mm, length: 400 - 3000 mm, thickness: 8 - 40 +/- 0. 2 mm
- Foil dimensions: maximum width: 1320 mm (side overhang up to 20 mm) roll diameter: 76 or 152 mm (3" or 6")
- Working height above floor: 940 mm
- System speed: 15 - 45 m/min
- Preheating and smoothing calender gkl, d = 500 mm
- Thermal oil heater 36 kw
Extra Information
Machine still under power. Stacking station Bargstedt is not in the line anymore.
