JUNKER - QUICKPOINT 5002/10 ES-GRI-JUN-2002-00001
Haben Sie weitere Fragen? Kontaktieren Sie uns!
Philipp Gubisch
+49 162 402 75 81
p.gubisch@gindumac.com
- GINDUMAC
- Produkte
- Werkzeugmaschinen
- ➤ Used JUNKER QUICKPOINT 5002/10 For Sale | gindumac.com
This 3-axis JUNKER QUICKPOINT 5002/10 was manufactured in 2002. It features a Siemens control system, Marposs measuring, and CNC-controlled Z-axis and grinding spindle head. With a grinding length of 1000 mm and a diameter up to 280 mm, it's ideal for precision surface grinding. Consider the opportunity to buy this JUNKER QUICKPOINT 5002/10 surface grinding machine. Contact us for more information about this machine.
Übersicht
- Hersteller: JUNKER
- jahr: 2002
- MODELL: QUICKPOINT 5002/10
- anwendungstyp: Schleifen
- Standort: Spanien
- maschinentyp: Flachschleifmaschine
Technische Daten - JUNKER QUICKPOINT 5002/10
Maße
- Maschinengewicht: 11000 kg
Zusätzliche Informationen
Grinding length between centers: 1000 mm
Grinding diameter: 280 mm
Workpiece diameter range: 20–80 mm
Turning diameter at grinding wheel height: 70 mm
Workhead spindle dimensions: 100 × 400 mm
Tailstock adjustment: Chain driven
Part clamping: Hydraulic
Axes:
Z-axis: CNC controlled
Grinding spindle head (X-axis): CNC controlled
Grinding spindle dimensions: 180 × 400 mm
Standard flange diameter: 127 mm
Main spindle motor power: 24 kW
Grinding wheel dimensions: 400 × 127 mm
Peripheral speed: 90 m/s
Additional equipment
Measuring system: Marposs
Balancing system: Electronic
*Es kann zu Abweichungen zwischen den angegebenen Daten und den tatsächlichen Werten kommen, diese müssen vom Vertriebsmitarbeiter bestätigt werden.
