This 7-axis EMCO HYPERTURN 45 G2 was manufactured in 2023, featuring a CNC Turning and Milling Center with Counter Spindle. It includes Siemens Sinumerik 840D sl control, dual spindles with a speed range up to 7,000 rpm, and a bar capacity of Ø45 mm. Ideal for complex machining, it comes equipped with two 12-station tool turrets and a chip conveyor system. Consider the opportunity to buy this EMCO HYPERTURN 45 G2 turn-mill centre. Contact us for more information.
Übersicht
- Hersteller: EMCO
- jahr: 2023
- MODELL: HYPERTURN 45 G2
- anwendungstyp: Drehen
- Standort: Deutschland
- maschinentyp: Dreh-Fräszentrum
Zusätzliche Informationen
Control System: Siemens Sinumerik 840D sl / OPERATE
Control Features:
emcoNNECT APP-based user interface
22” multi-touch display
IPC with 240 GB
SHOPTURN dialogue programming
USB and Ethernet interface
Network drive
3D simulation and advanced visualization
Main spindle power: 15 kW
Counter spindle power: 15 kW
Speed range: 0–7000 rpm
Spindle connection (DIN 55026): KK5
Max. bar capacity: Ø45 mm
C-axis on both main and counter spindle
TRANSMIT software for simple C-axis programming
2 × 12-station VDI 25 radial tool turrets
Logic for up to 2 × 12 driven tool stations
Adjustable swivel speed with feed switch
Driven tools: Max 4 kW at 2080 rpm, 16 Nm torque, 0–6000 rpm
Hollow clamping cylinder on main spindle
Draw tubes for main and counter spindle
Mechanical spindle brake (main/counter)
Part ejector and flushing through counter spindle
Air gun with spiral hose
CNC lathe for complete machining of turned and milled parts equipped with 2 spindles, 2 tool systems, 5 linear axes, and 2 rotary axes
Integrated spindle motors (water-cooled) with preloaded roller guides
Chip conveyor: Hinged belt type, programmable, ejection height 1100 mm
Integrated coolant unit in the chip conveyor
2 × high-pressure pumps (14 bar)
2 × flushing pumps (3.7 bar)
LED machine room lighting
Hydraulic power unit
Complete documentation
*Es kann zu Abweichungen zwischen den angegebenen Daten und den tatsächlichen Werten kommen, diese müssen vom Vertriebsmitarbeiter bestätigt werden.
