This 5-axis AccuteX AP 4030A wire EDM machine was manufactured in 2022, featuring a submerged design for enhanced precision and stability. It supports a maximum workpiece size of 800 x 560 x 245 mm and a weight up to 800 kg. Key features include AWT for reliable wire threading and a high-resolution 17” LCD-TFT screen for advanced control. Ideal for complex, high-accuracy tasks. Contact us for more information about this machine.
Übersicht
- Hersteller: AccuteX
- jahr: 2022
- MODELL: AP 4030A
- anwendungstyp: Erodieren
- Standort: Deutschland
- maschinentyp: Drahterodiermaschine
Technische Daten - AccuteX AP 4030A
Maße
- Maschinentiefe: 2150 mm
- Maschinenhöhe: 2250 mm
- Maschinengewicht: 3200 kg
Bewegung
- Anzahl der Achsen: 5
- X-Achsverfahrweg: 400 mm
- Y-Achsverfahrweg: 300 mm
- Z-Achsverfahrweg: 270 mm
Zusätzliche Informationen
Machine Benefits
Qualitative Machine Benefits
- Separate axis design for reduced errors
- Electric-drive safety lock and automatic lift for usability
- Advanced wire control technologies for precise operations
- Adaptive control systems and high-resolution processors for enhanced precision
Technical Machine Benefits
- Wire diameter range: 0. 15–0. 3 mm (0. 05–0. 1 mm optional)
- Optional 6th axis rotary table: fully submersible (ip68), with 720000 pulses/rev for ultra-high resolution
- Tank capacity: 600 liters
- Ion resin tank capacity: 10 liters
- Display: 17” lcd-tft screen
- Best surface roughness: ra 0. 35 μm
- Cutting accuracy: ±2. 0 μm
- Max cutting speed: 240 mm²/min
Extra Information
Machine still under power
*Es kann zu Abweichungen zwischen den angegebenen Daten und den tatsächlichen Werten kommen, diese müssen vom Vertriebsmitarbeiter bestätigt werden.
